4000-662-888| Model | Studio Size? (D*W*H)mm | Dimension（D*W*H）mm | |
| LRHS-45Z-HAST | ?450×500 | 約1600×950×1600 | |
| temperature range | 105℃～143℃ | ||||||
| Humidity range | 75%RH ～100%RH | ||||||
| Pressure range | 0.02 M pa to 0.196 M pa (gauge pressure) 0.2kg/cm2 to 1.96kg/cm2(gauge pressure) |
||||||
| control accuracy | Temperature: ±0.3°C / Humidity: ±3.0%. | ||||||
| heating time | Room temperature～130℃/85%RH about 100 minutes | ||||||
| Outer case material | SUS#304 high tensile stainless steel plate, and through the multi-layer film free layer surface treatment | ||||||
| Inner box material | SUS#316 Heat resistant and cold resistant stainless steel plate | ||||||
| Insulation material | High Density Glass Wool | ||||||
| heaters | Electric heater made of 316 stainless steel | ||||||
| Heating systems | Electric heater made of 316 stainless steel | ||||||
| security protection | Over-temperature, fan motor overheating, leakage protection, overall equipment timing and short-circuit protection | ||||||
| Supply Voltage | AC220V±10% 50±0.5Hz | ||||||
| operating environment | 5℃～＋35℃ ≤85% RH | ||||||
| Note: 1、the above data are measured in the use of ambient temperature of 25 ℃ and well-ventilated conditions 2、Can be customized according to the specific requirements of the user non-standard HAST test chamber etc 3、This technical information is subject to change without prior notice. |
|||||||
