4000-662-888| Pseudolaric acid | Water immersion test device | |
| waterproof rating | IPX7、IPX8 | |
| The volume of the equipment is | Diameter 1000mm*Height 1200mm | ||||||
| Opening method | Pneumatic lift with manual safety latch | ||||||
| Pressure range | 0～3kg (imitating 30m water depth test) | ||||||
| drip area | 800mm×1000mm | ||||||
| Note: All processed by SUS304 stainless steel, stainless steel material wall thickness of 10mm; Can simulate 30m water depth pressure (MAX: 3KG/M3), the immersion depth can be operated directly on the panel; Container water inlet for automatic control, and with water purification and treatment devices (drainage for automatic control); With a liquid level meter can show the height of the water level in the container, the test duration can be set, and with a prompt function (test pieces have special requirements can be customized); IPX7/X8 submersible test device is a non-standard product, the height, diameter and pressure range of the device are customized according to the customer’s requirements or the size of the product. |
|||||||
| security protection | Integral device under-phase/reverse-phase, integral device timing, leakage protection, overload and short-circuit protection | ||||||
| Supply Voltage | AC380V±10% 50Hz | ||||||
| Note: 1、the above data are in the use of ambient temperature of 25 ℃ and well-ventilated conditions measured 2、Can be customized according to the specific requirements of the user non-standard water immersion test device, etc 3、This technical information is subject to change without prior notice. |
|||||||
